Forged Flanges

Forged Flanges

MOQ : 1 Ton

Business Type Manufacturer, Exporter, Supplier

Preferred Buyer From

Location All Countries Except India

Highly acclaimed Manufacturer & Supplier of Forged Flanges, SS Forged Flanges, Carbon Steel Forged Flanges, Stainless Steel Forged Flanges, Alloy Steel Forged Flanges, Inconel Forged Flanges, Monel Forged Flanges, Hastelloy Forged Flanges in India

We are largest manufacturers of Forged Flanges & have huge stock of 304 Forged Flanges, 316 Blind Flanges, astm a105 Forged Flanges, astm a182 Forged Flanges as per asme / ansi B16.5 forged flanges, ansi B16.47 forged flanges, Din forged flanges, jis forged flanges & uni forged flanges Standards.

we offer high quality Forged Flanges in all size, classes & dimensions like Class 150 Forged Flanges, Class 300 Forged Flanges, Class 900 Forged Flanges, Class 1500 Forged Flanges & Class 2500 Forged Flanges

Forged flange, It is invented on the basis of the cast flange into production, its intensity to be higher than the cast steel flange many interconnected so that the tube with the tube parts, is connected to the tube end.

the forged flange has the higher production cost, but the lower carbon content, higher rust resistance, better seamline, intensive inner texture, and stronger mechanical property than the cast flange. The forging craft will not make the coarse or uneven-sized grains, so the crack caused by solidification will not happen on the forged flange.

We are largest Manufacturer, Supplier and Exporter of Forged Flanges, ASME 16.5 Forged Flanges. Forged Flanges are used on heat coupling of pipes and are customized as per the specifications of our clients. We offer a comprehensive range of Forged Flanges including SS Forged Flanges, Carbon Steel Forged Flanges, Alloy steel, Nickel Alloy, Duplex Steel Forged Flanges etc. We maintain a strict quality parameter check on our product and we are committed in timely delivery.

Read More...


Details

Type Forged Flanges, ASME 16.5 Forged Flanges
Size 15 NB to 750 NB, 1/2-78 inch (DN15-DN2000)
Material Stainless Steel Forged Flanges: ASTM A182 F202, A 240 F 304, 304L, 304H, 316, 316L, 316Ti, 316LN, 310S, 317L, 321, 410, 420, 440C, 202. F904L
Carbon Steel Forged Flanges: A-350 LF2 LF3, A105
Duplex Steel Forged Flanges: ASTM / ASME SA 182 F 44 , F 45 , F51 , F 53 , F 55 , F 60 , F 61.
Alloy Steel Forged Flanges: ASTM A182 F1, F5, F9, F11, F22, F91
Special Alloy Forged Flanges: Duplex, Super Duplex, Nickel Alloys
Nickel Alloy Forged Flanges: Cupro Nickel (90/10, 70/30, 66/30/2/2), Hastelloy (C-4, C-22, C276, B-2), Nickel (200 / 201 / 205), Monel 400 & K500), Inconel (600, 601, 625 & 825), Incolloy (800, 800H), Alloy 20, Duplex Steel, SS 904L, Titanium (1 & 2) Etc.
Standard ANSI : ANSI B16.5, ANSI B16.47, MSS SP44, ANSI B16.36, ANSI B16.48 ,JIS,DIN,BS4504,SABS1123,EN1092-1, UNI,AS2129,GOST-12820
DIN : DIN2527, DIN2566, DIN2573, DIN2576, DIN2641, DIN2642, DIN2655, DIN2656, DIN2627, DIN2628, DIN2629, DIN 2631, DIN2632, DIN2633, DIN2634, DIN2635, DIN2636, DIN2637, DIN2638, DIN2673
B.S : BS4504 , BS4504, BS1560, BS10
Pressure Class Class 150, Class 300, Class 400, Class 600, Class 900, Class1500, Class 2500 | PN6, PN10, PN16, PN25, PN40, PN64 etc.
Specialize As per drawing
